TB-D50 Single Side Self-adhesive Labeling Machine
Specifications
|
No. |
Component |
Model |
Qty. |
Brand |
From |
|
1. |
PLC |
FX1S |
1 unit |
MITSUBISHI |
Japan |
|
2. |
Touch screen |
TK6070IK |
1 unit |
Weinview |
Taiwan |
|
3. |
Photoelectric sensor |
FX-301 |
1 pc |
Sunx |
Japan |
|
4. |
Photoelectric sensor |
FX-301 |
2 pcs |
Sunx |
Japan |
|
5. |
Servo motor 1 |
MBDDT2210003 (750W) |
1 unit |
Panasonic |
Japan |
|
6. |
Servo drive 1 |
MHMD042PIU (750W) |
1 unit |
Panasonic |
Japan |
|
7. |
Inverter |
BFV00022DK |
2 units |
Panasonic |
Japan |
|
8. |
Pinch motor |
5IK60GK-YF/5GK-9 |
2 units |
OPG |
Taiwan |
|
9. |
Motor transport |
RV40-180-25-FL-B5 |
1 unit |
OPG |
Taiwan |
|
10. |
Switch knob |
XB2-BD21 |
1 unit |
Schneider |
France |
|
11. |
Switching Power Supply |
S-35-24 |
1 pc |
MW |
Taiwan |
|
12. |
AC contactor |
LC1-D1810M5C |
1 pc |
SM |
Shanghai |
|
13. |
Circuit Breaker |
DZ47-36 |
1 pc |
SM |
Shanghai |
|
14. |
exhaust fan |
SF11025AT |
1 pc |
Luann |
Shanghai |
Technical Parameter:
Model: TB-D50
Drive: by servo motor
Labeling capacity: 100BPM (subject to label and bottle size)
Label feeding speed: ≤35m/min
Labeling accuracy: ±1mm
Label material: glassine paper base
Label inner diameter: φ76mm
Label outer diameter: Max φ350mm
Label max width: 200mm
Label width: 15-150mm
Label length: 15-300mm
Machine size: 2800*1350*1500mm
Power: 220V 50/60Hz 1kw
Weight: 500kg
